China High-Performance Audio Frequency Transformer with 20Hz - 20kHz Operating Frequency and IEC 61558-2-6 Compliance wholesale

High-Performance Audio Frequency Transformer with 20Hz - 20kHz Operating Frequency and IEC 61558-2-6 Compliance

Name: HighPerformance Audio Frequency Transformer with 20Hz 20kHz Operating Frequency and IEC 6155826 Compliance
Brand: SHINHOM
Price: 1 USD

Ask Latest Price

Video Channel

Brand Name :SHINHOM

Model Number :ACST13

Certification :RoHS

Place of Origin :China

MOQ :5000

Payment Terms :L/C,T/T

Delivery Time :2~8weeks

Operating Frequency :20Hz - 20kHz

Insulation :Triple-layer electrostatic shielding

‌Storage Temperature‌ :-40°C to +105°C

Core Material‌ :High-permeability nickel alloy

Contact Now

Add to Cart

View Product Description

Designed for high-performance audio signal processing systems, the ACST13 Series delivers precision impedance matching with exceptional linearity across the full frequency spectrum. Utilizing advanced core materials and balanced winding techniques, this low-frequency transformer maintains signal integrity while achieving ultra-low electromagnetic interference. The vacuum-impregnated construction ensures compliance with international safety standards, making it ideal for critical audio path applications.

‌Features‌

•Frequency Response: ±0.1dB (20Hz-20kHz)

•Primary Inductance: 250mH ±15%

•DC Resistance: 12Ω (Primary) / 280Ω (Secondary)

•Turns Ratio: 1:1.5 ±2%

•Power Handling: 100mW max

•Insulation Resistance: ≥100MΩ

•Operating Temperature: -20°C to +85°C

‌Technical Specifications‌

•Core Material: High-permeability nickel alloy

•Winding Configuration: Triple-layer electrostatic shielding

•Mounting Style: Through-hole PCB mounting

•Pin Spacing: 10mm × 12mm standard grid

•Weight: 18g typical

•Safety Standards: Meets IEC 61558-2-6 isolation requirements

‌Applications‌

Professional Audio Equipment: Microphone preamplifiers, console channel strips

Broadcast Systems: Audio distribution amplifiers, mixing console I/O stages

Test Instruments: Audio analyzer input/output isolation

Medical Audio: Patient monitoring equipment audio circuits

Communication Devices: VoIP conference system analog interfaces
